P. 106

RIDE COMFORT & EQUIPMENT


       For large panel vans




                                                                    Seat/sleeper bench system VARIO-
                                                                    TECH® 3100Q
                                                                    The comfort solution for the VW Crafter 2 from year of
                                                                    construction 2017,
                                                                    tested according to ECE R14 + ECE R17
                                                                    The system consists of a VARIOTECH® 3100 bench seat with 2
                                                                    three-point belts and a special base with transverse sliding unit
                                                                    For sleeping, the bench is shifted sideways approx. 200 mm,
                                                                    seat width approx. 120 cm, sleeping surface approx. 140 x 195
                                                                    cm. The bench is intended to be installed with a platform
                                                                    towards the driver's cab. Platform height 80 mm. Delivery ready
                                                                    upholstered with cover fabric Classic grey, including sleeping
                                                                    accessories and installation material.
                                                                    Variotech® 3100Q  5049000  Price on request





















                                                                    Single seat A400

                                                                    The approved seat with three-point belt for Mercedes
                                                                    Sprinter, VW Crafter and Fiat Ducato.
                                                                    In combination with the aluminium slide rail, the seat can be
                                                                    moved or removed. Choose from 2 base heights to find your
                                                                    comfort position. You need one right and one left pedestal. A
                                                                    maximum of 3 seats can be mounted in one row.
                                                                    Single seat A400 with 2 armrests
                                                                    Seatbelt connection left  59372  1199,--
                                                                    Belt connection right  59371    1199,--
              Body widening for MB Sprinter                         Seat base height 23 cm (seat height 41 cm)  137,90
                                                                                           59366
                                                                    left
              For Mercedes Benz Sprinter from year of manufacture xxxxx, vehicle length:  right  59365  137,90
              6 m. Position: driver's side. Extends the interior by approx. 80 mm. Material:  Seat base height 28 cm (seat height 46 cm)
              GRP, surface: gelcoat white, paintable                left                   59368     137,90
                            15096       529,--                      right                  59367     137,90
                                                                    Aluminium slide rail, double row, for mounting one seat or
                                                                    several seats in a row. Approx. 1 meter seat rail required per
              Sliding door distance kit for VW Crafter and          seat. Length 2,40 m    59379     376,--
                                                                    Special adhesive (600 ml) for bonding the floor rail
              MB Sprinter                                                                  593795     28,95
              The sliding door distance kit is needed if a body widening is mounted on the
              passenger side. The kit extends the distance between the open sliding door
              and the vehicle body. This allows the sliding door to be opened completely
              even when a body extension is mounted.
                            28500         xx,xx








      106   www.reimo.com
