Technical specifications Weekender
short wheelbase:

Sleeps on sleeper/seat bench 2
Sleeping places with optional sleeping roof 4
Light bed dimensions approx. 205 x160 cm
Sleeping/seating bench: Variotech® 3000
Seats with three-point seat belts 5
Rear storage space Base plate 3-piece
- with / without bench seat: 3100 l / 5100 l Sleeping/seating bench Variotech® 3000
Sliding and removable bench. For vehicles with-
- under bed extension: DxWxH 63x122x40 cm out plastic side panelling. Three-seater, size 17, Made of waterproof chipboard with PVC covering.
For original VW sill rail. Rail distance 997 mm. Dé-
- under bench: 43 x 75 x 28 cm / 90 l
total bench width: 1380 mm .Upholstery width: cor: ship's bottom
1330 mm, sleeping surface: approx. 2050x1600 1053842 423,32
mm. 3 integrated retractable headrests, safety
belts. Isofix attachment points for max. 2 child
seats (middle seat not usable when using a child X-Trem insulator, 18 mm thickness
seat), fold-up rear upholstery (storage space Extremely heat insulating and very light insula-
tion. Required under the floor slab 2xfr kR. Sup-
height under rear upholstery: 46 cm), front panel plied as panels of 2 x 1 m.
and side panel. Fully upholstered incl. rear cush-
ion. Rail spacing 997 mm. Fabric design: Classic 50009 26,50
grey, 2-color
Day position 5040300 4359,--
Glide bar set “Grizzly "
For Variotech® 3000 kR
58200 419,-
Fastening kit
For "Grizzly" sliderail set for short wheelbase. For
fastening the slide rails to the vehicle floor. Rail
spacing 997 mm.
Night position 58202 219,--
Alternatively, the Variotech® 3100 rigid
sleeper/seat bench (size 17)can be installed.
For all details, see page 151.
Vehicle video
view

Table decor mandarin
Table system with swivel table frame
With bracket for attachment to the front panel of
the bench. Table top in laminate, decor
Mandarin, dimensions approx. 85 x 47 cm.
Table edge silver.
18052 289,--

Drawer
Provides additional storage space for e.g. shoes,
cables or on-board tools. The drawer can be re-
moved for loading long parts. Dimensions HxWxD:
approx. 17x83,5x69,5 cm. Décor: Basalt
5040390 679,--
Front panel
Mounted on the bench instead of a drawer. The
front panel is removable and therefore offers a
through-loading possibility for e.g. surfboard or Hanging roof cabinet for EasyFit sleeping
skis up to a length of max. 2.4m (through-loading roof with slatted bed
dimensions under the bench As prefabricated part above rear bench seat for
For further equipment and HxW approx. 31x80 cm). Decor: Basalt additional storage space. Cabinet pre-
options, please contact your 5040380 249,-- assembled. For short or long wheelbase with
decor: anthracite metallic.
dealer
10820L 599,--
