CAB ADDITIONAL BEDS

• Total height: 8 cm (7 cm thick cold foam mattress
and 1 cm thick MDF board)
• Cover (100% polyester fabric) removable and washable
• 2-fold foldable (weight approx. 11 kg)
• Colour: Grey
Fiat Ducato (also Ducato 8), Peugeot Boxer,
Citroën Jumper > 2002 421742 219,--
Volkswagen T6.1, T6, T5, T4 421743 219,--
Volkswagen Crafter, MAN TGE > 2017 421744 229,--
Mercedes-Benz V-Class, Vito Tourer > 2014 421745 229,--
Mercedes-Benz Sprinter > 2018 421746 229,--
Renault Trafic, Fiat Talento, Nissan NV300,
Opel Vivaro > 2002 421747 229,--
Ford Transit Custom > 2013 421748 229,--
Citroën Spacetourer/Jumpy, Peugeot Expert/Traveller,
Toyota Proace, Opel Zafira, Fiat Scudo > 2015 421749 229,--
Fig. shows Mercedes-Benz V-Class
Optional carrying bag 421750 49,95

ELECTRIC LIFTING BEDS
a
Complete set for Fiat Ducato, Peugeot Boxer,
Citroën Jumper, Mercedes-Benz Sprinter a
• Extra-light aluminum profiles (weight approx. 35 kg)
• Loadable up to max. 400 kg
• Infinitely height-adjustable b
• Mechanism integrated into the frame under the slatted frame
The electric fold-down bed from CARBEST is characterized by its high-quality
workmanship and intuitive assembly. It is infinitely height-adjustable. The extra
light weight (approx. 35 kg) is achieved using sturdy aluminum profiles. The
static load capacity is 400 kg. The height adjustment speed is 33 mm/second, b
with a consumption of only 6-7 A / 12 V.
The maximum stroke (travel) is 900 mm. The lifting bed is maintenance-free.
Including slatted caps for the slatted frame for optimum reduction of mechanical
noise while driving.

1513
a Lifting bed with cable pull for Fiat Ducato, 7 120,9 WIRE EXIT 480
Peugeot Boxer, Citroën Jumper 20
1513
1513 7 120,9 WIRE EXIT 375 480
WIRE EXIT
120,9 Scope of delivery:
7 1 drop-down bed 1755 x 1325 mm 480 480
1 mattress 1755 x 1325 mm 20
20 1 trolley right / 1 trolley left 1325 375
2 front bed attachments 375 480
2 bed rails 375
1 fixing point at the rear left 480 1325 143,8°
1 fixing point at the rear right 151 375
1325 2 front mounting plates 54 120,9 116
1 electrical component (motor) 143,8° WIRE EXIT
Frame colour black 93957 1899,-- 375 151
54 120,9 116 WIRE EXIT
