Access hatch with access ladder

45 cm legroom in the roof bed for high sleeping comfort
Sleeping roof Fiat Ducato* from length L2, height H2
The positioning of the roof is designed in such a way that an existing cut-out of
a Heki directly behind the driver's cab can be used as a hatch
The GRP frame then ends exactly in the area of the transverse bead of the
roof sheet. Roof hatches located behind the transverse corrugation can be re-
tained. The positioning results in a roof bed length from the cutout of 180 cm,
which can be extended to 2 m with an additional part if required (optional). In-
stallation height approx. 18 cm.
Simultaneous installation of an awning is possible thanks to awning adapter
cutouts on the sleeping roof. If no awning is installed, an optionally available More maxi van sleeping roofs:
cover set can be inserted into the recesses.
Sleeping roof VW Crafter from year of construction 2017,
H3 vehicle height 262 cm, at 6 m vehicle length
Sleeping roof for Fiat Ducato L2 H2, White 28066906 5290,-- The roof is positioned so that the access can be made in the roof hatch area
Sleeping roof for Fiat Ducato L4 H2, white 28066902 5190,-- behind the bar in the sliding door area. Body height approx. 24 cm.
Sleeping roof for Fiat Ducato L4 H2, black 28066903 5690,--
28066541 5490,--
Sleeping roof Maxivan Ducato
Bed cushion 120 x 180 cm 280670 438,70 Sleeping roof Mercedes Sprinter from year of construction
Bed extension Maxivan Ducato sliding board with bed cushion 120 x 20 cm, 2006, at 6 m vehicle length body height approx. 22 cm
for extending the roof bed to 2 m sleeping length 280672 149,-- 28066361 5490,--
Access ladder for easy access to the roof bed 42122 164,50 Universal sleeping roof for large vans
Cover set for awning adapter recesses 28066-2 Price on request e.g. Renault Master, Ford Transit or Hyundai H 350.
*also suitable for C. Jumper, P. Boxer as of 2006, Opel Movano as of Note: Lower frame, spoiler and possibly frame must be adapted
28066001
5390,--
2021,Ram Promaster as of 2009
Roof bed VW Crafter, Mercedes Sprinter and Universal suitable
for above listed roofs Bed cushion 120 x 200 cm, ventilated
28067 438,70
