ACCESSORIES FOR SLEEPING ROOFS

Active carrier rail set installed on the sleeping Thule roof rack system for pop-up roofs
roof Basic equipment for all types of vehicles with Reimo active
(please order also, can be poorly mounted afterwards) Ideal for con- carrier profile
cealed mounting of a roof rack. 4 pieces of approx. 40 cm each
(mounted) 41320 370,-- Adapter plates enable the attachment of Thule fixed points 543 in the
Reimo active rails Scope of delivery: 4 adapter plates, adapter plate
Active carrier profile 40 cm for retrofitting Thule roof rack 64 mm 41304 51,90
Counter plate visible from inside can be covered with Isovelour (51015). 4 Thule fixed point 543 The artificial fixed points replace the mounting
pcs. with counter plate, seal and screws 41303 290,-- points on car roofs. Set with 4 pieces incl. mounting material
41082 103,--
Thule Support Foot Rapid 753 Set of 2 41093 74,99
Thule Support Foot Rapid 751 Set of 2 41092 74,90
Thule Wingbar 135 cm, 1 piece 410969 140,--
Thule Wingbar 150 cm, 1 piece (without picture)
410967 140,--
Thule Slidebar 127 cm, 1 piece 410964 290,--
Thule Slidebar 144 cm, 1 piece 410963 320,--

Material needed Thule Support Thule Support Suitable Mountable carrier
Mounting Foot Rapid 753, Set Foot Rapid 751, Set (required quantity 2 pieces)
Vehicle specific of 2, Art.no. 41093 of 2, Art.no. 41092 mounting kit
VW Caddy 2x 41091 Slidebars 127 cm, 1 piece, item no.
VW T5/T6 without superstructure or flat solar panel 2x Wingbars 135 cm, 1 piece, item no. 410969
on request or
VW T5/T6 with higher installations on roof 2x Slidebars 144 cm, 1 piece, item no. 410963

Renault Trafic without higher roof superstructure 2x Wingbars 150 cm, 1 piece, item no. 410967
on request or
Renault Trafic with higher roof superstructure 2x Slidebars 144 cm, 1 piece, item no. 410963

Roof support for Reimo Multirail
100 kg Support feet (2 pieces) especially suitable for
Reimo Multirail rail, Reimo Active rail and for rain
gutter mounting. Max. load 100 kg pair of sup-
port feet: Height 20 cm 41180 89,95
Support tube: length 165 cm for above men-
tioned support foot. Square tube 32 x 22 mm,
black plastic coating. TÜV approved. The roof
support must be removed before opening the
sleeping roof. Per piece 41125 41,90

NOTE: Order accessories when ordering the sleeping roof. Subsequent installation is possible, but usually involves significantly higher costs
and technical compromises. Standard colour of the roofs white, illustrations partly show additional equipment. Subject to technical changes
and printing errors.
