Technical specifications
Sleeping places on bed surface 2 Light bed di-
mension lR Single bed: 195x70/87 cm Double
bed: 195x116/132 cm Bench seat: Original VW
Seats with three-point belts max 5
Living bench for 2 persons in the rear
Kitchen block with folding sink
Fresh/waste water 10/10 liters
Compressor cooler approx. 10 L
Interior lining original VW Caddy
Floor plate in the rear of the vehicle to accommo- Bed with folding bench seat Camp stowage box (optional) for Caddy kR
date The single bed consists of a left folding part and and Maxi lR from year of construction Sept.
Bed corpus and kitchen block the folding bench seat, which is positioned on 2010. Is used instead of the original 2-seater
the VW 2 seat. Sleeping surface of the single
bench seat under the folding bench seat with
Variable cargo space size by folding up bed and bed: 195x70/87 cm. Next to it remains a lot of cushion from art. no. 14502 without tools. Dimen-
bench seat space, for example, for sports equipment. The sions: L 51 x W 85 x 33 cm.
Optional large storage box for exchange against single bed can be extended to a double bed by 13505 515,--
original rear bench Optional storage box for mo- the kitchen box. The cushion on the kitchen box
bile camping toilet Porta Potti 335 Cube in ex- increases the sleeping surface to 195x116 cm
change against single bed or 132 cm with the cushion in front. All parts can
Vehicle electrics: remain installed even with 5 people on board.
Includes the following upholstered
Original Caddy 12 V system with interior lighting, parts:
2nd battery system optional
14602 1499,--

Base vehicle:
Suitable for VW Caddy Maxi, Life, Style with origi-
nal plastic trim.
Dimensions (LxWxH): 4.85 m x 1.85 m x 1.80 m Storage box for portable toilet
The stowage box is used instead of the single
seat on the passenger side. It offers space for
the Porta Potti 335 Cube. Or for other utensils
like shoes, tools etc. Can be exchanged for re-
movable single seat without tools. (Toilet op-
Kitchen box tional) Dimensions: L 63 x W 42,5 x 35 cm.
The kitchen box can be extended over the rear of
Day position the vehicle. This allows convenient cooking out- 13507 409,--
side the vehicle. The kitchen box is equipped
with two 10-liter canisters, a gas cartridge stove Cushion pad for above storage box/table Is
and a folding sink. A cool box can be optionally needed on the table top or for the double bed.
accommodated in the front, fixed area of the Can be used in combination with the storage box
kitchen box. The kitchen box extends the sleep- 13507, alternatively with the table unit (if storage
ing width of the bed to the entire interior width box is not available). To widen the sleeping sur-
Night position (195x116 cm). Includes the following uphol- face in front of the kitchen box to 132 cm. Uphol-
stered part: stered part:
14601 1590,-- 145070 199,--

Weekender base plate, decor Tessin
14500 169,--

Technical package in bed box partially installed
12V and 230V system, switch-mode charger 20A, Compressor cooler Cool`N'Heat
AGM battery with 60Ah power, charge booster (WA for kitchen box
121525). CEE surface-mounted socket, voltmeter, The 10 l compressor cooler with 2 functions:
universal socket, 13A circuit breaker with RCD, 230V Camp table system Cooling and heating. Operation via LCD touch
built-in socket, power socket up to max. 20A, USB The table top is stowed on the backrest of the display. With sturdy handle and 12/24V connec-
built-in socket, 50A fuse holder. (The CEE sockets single seat, where it serves as a bed support. tion cable. Weight approx. 8 kg.
and power connections to the booster must be in- Incl. table base and table glides. Table top: 713545 425,-
stalled in the vehicle) 70x44 cm, Pearl decor, anthracite.
14502TE 1290,- 14503 169,-- Porta Potti 335 Cube 660102 169,50
