P. 39

Long, day position









                                                                                            Long, night position


































        Sleeping                   Living                     Loading and storage space  On-board technology
        The fold-up, comfortable rear bed for  With the folding bench seat and seat-  The bed folds up on both sides to  Standard with original Caddy 12 V sys-
        the VW Caddy Maxi lR (My. 8/2010 -  ing opposite, it makes a cozy 2-4  create maximum loading volume (bi-  tem and interior lighting
        8/2020) goes over the entire interior  person seating area.  cycle, etc.), and also leaves a stor-  Optionally available:
        width of the vehicle. It offers a sleep-  Entry through the sliding door is  age space under the bed level. Max.  • 230 volt system mounted Carbest
        ing area as a single bed of approx.  possible on the right or left. Stand-  Rear storage space with installed  switch-mode charger 15 A, circuit
        200x70 cm and as a double bed of  ing height is achieved by the op-  equipment: approx. 2.4 m³  breaker 13 A with FI, signal light
        approx. 200x145 cm. The 2-person  tional sleeping roof. For high flexibil-  Optionally available  230 V. 230 V built-in socket with
        bed area can be divided in the mid-  ity, a table top can be mounted               frame. With CEE socket including
        dle. Used as a single bed, there is  either on the right or left side.  • Large stowage box to be ex-  cable for laying and connection in
        still plenty of space next to it, e.g. for  Table system incl. table base and  changed for VW-2 bench for more  the vehicle (self-installation)
        sports equipment. The fold-up bed  table slide rails. Table top approx. 70  stowage space of 115 liters.  135011TE  526,--
        can also be left in place for larger  x 44 cm, Pearl decor, anthracite  Dimensions: approx.  • Diesel parking heater Carbest
        transport tasks or with 5 people on  color.  13503  233,--  L 51 x W 85 x 33 cm    VanHeat 2.0-DH 2kW power, inte-
                                                                                515,--
                                                                         13505
        board.                     Base plate  13500  249,--  • Box for Porta Potti 335 Cube  grated altitude adjustment up to
        Rear bed with folding bench seat,                       camping toilet to exchange for VW  5.000 m, type approval according
        incl. 7-piece cushion set                               single seat behind passenger. Di-  to UN ECE R122, approval by the
        13602      2379,47                                      mensions: L 63 x W 42 x 35 cm  German Federal Motor Transport
                                                              Dust box for portable toilet  Authority according to UN ECE
                                                                         13507  409,--     R10, including LCD control panel,
                                                              Porta Potti 335 Cube         tank extraction set and extensive
                                                                         660102 169,50     installation material
                                                                                                  48182     649,-
                                                                                                www.reimo.com  39
