CARAMOVE

CARAVAN MANEUVERING SYSTEMS

Cara-Move II - fully automatic caravan shunting system
2 x SOFT SOFT
AUT0 7 years
START STOPP Parts warranty

• Automatic engagement drive
• Move the caravan effortlessly, up to 2250 kg
• Lightweight due to plastic cover
• Easy and stress-free maneuvering with the Smart Handset
• Suitable for single and double axle caravans with two axles
4 motors are required for all-wheel drive (2x 920209)

Smart Handset & Control System
Simple and intuitive operation. Precise maneuvering due to the unique roller-ball
design. Variable speed control and 360° fluid movement, So you really effortlessly
control your caravan.
Speed: 12 cm/sec, Operating voltage: 12 V DC Weight (2 motors): 23 kg, Combined
weight (incl. installation kit etc.): approx. 34 kg
Max. Climbing capacity according to total weight:
15% - 2500 kg / 20% - 2250 kg / 25% - 2000 kg
Scope of delivery: 2 motors, mounting bracket, remote control, battery disconnect
switch (100 A), rocker arm, mounting hardware, operating instructions
920209 1449,--

7 years
Parts warranty
Cara-Move - powerful, semi-automatic shunting system
2 x
½ SOFT SOFT
CAR START STOPP

• Soft start precision control
• Compact, stable, reliable
• Suitable for single and double-axle caravans with two axles,
4 motors are required for all-wheel drive (2x 920208)
• Convenient control with remote control
The manual caravan maneuvering aid moves single and double axles up to a maximum
total weight of 2250 kg. The aluminum drive roller is swiveled on and off manually.
Current consumption on level ground: app. 25 A. Max. Current consump.
(1100 kg caravan single-axle, slope 25%): 80 A, Weight: 35 kg
Max. Climbing capacity according to total weight:
15% - 2500 kg
20% - 2250 kg
25% - 2000 kg 1150,--
Scope of delivery: 2 motors, mounting bracket, remote control, battery disconnect
switch (100 A), rocker arm, mounting hardware, operating instructions
920208 1150,--
In some countries, the installation must be checked by a professional technician to comply with local regulations.
Optional fitting adapters
Low profile housing adapter plates Narrow gauge chassis adapter
If your chassis frame height is less than These plates must be used if you have an AL-KO
140 mm, these plates must be installed to Vario III/AV chassis that has a frame thickness
lower assembly to the correct height of of less than 2.8 mm.
185 mm. Pair E6205 36,-- Pair E6206 36,--

16 mm spacers Set of 8 screws M 10 x 100
Use spacers to lower the maneuvering aid Set of 8 extended clamping bolts for use with
assembly if your chassis has a frame height 16 mm spacers (E6204).
between 140 and 185 mm. E6207 12,95
Pair E6204 40,50

In some countries, the installation must be checked by a professional
technician to comply with local regulations.
