P. 162

SWIVEL CONSOLES for VW Transporter




        For VW T6.1/T6/T5
                                                       With                       Without                    With
                            With                       TÜV                         TÜV                       TÜV
                            TÜV






                                                                  35 mm                      25,5 mm

         For original seat FS/BFS from 2003  For original seats VW T5 / T6  For original seat FS/BFS from 2003 Swivel console from year 2003
         onwards   59699    164,99  (single seats) from 2003 onwards  onwards If original battery is installed  Installation only if there is no battery
                                   Driver's side  595717  255,--          59502   245,--  under the seat. Driver's side incl. hand-
         Matching handbrake lowering  Passenger side 595716  255,--  Matching handbrake lowering  brake lowering 59498  259,--
         necessary for swivel console driver's  Handbrake adapter without leatherette  necessary with swivel console driver's side. Passenger side 59499  239,--
         side                      cuff       595718   43,65   Left hand drive 59616  35,95
                   59616     35,95                             Right hand drive596160  35,95
                                Without                With                      Without                    Without
                                 TÜV                   TÜV                         TÜV                       TÜV






                                                                                             42 mm
         VW T5 for original double seat                        For original seat from 2003 -
         bench My. 2003-2015                                   With safe                  Adapter Sportscraft seat
         Test number: 76/115/EEC. Dimen-  VW T5 for original double seat bench Driver side/passenger side  from My. 2003
         sions in mm: L 605 x W 406 x H 229  My. 2003-2015               59647     459,--  Incl. slide rails For mounting
         (without screws)          With parts certificate. Without cable  Matching handbrake lowering neces-  Sportscraft seats on original or
         Left hand drive  594962 584,--  grommet.              sary with swivel console driver's side  swivel consoles
         Right hand drive 594961 555,--  Left-hand drive 59496  639,--  Left hand drive 596471  21,95  596451  299,--

                        Without    Swivel console for original seat from year 2003
                         TÜV       •No increase in seat height                  With
                                   •Rotation of the seat possible even with the
                                    door closed                                 TÜV
                                   With mounting hardware including handbrake
                                   lever adapter. TÜV tested with parts certificate.
                                   Locking in driving direction or also in 180°                            With
                                   position possible. Handbrake lever can be                               TÜV
         Seat base for             mounted individually. Outside dimensions:
         original seat from 2003 onwards  430 x 430 x 210 mm. Weight approx. 17 kg.     Swivel console for VW T5/T6
         Height adjustable: 230 - 360 mm,  Driver's side  59593  306,--                 For battery installation. Height 250 mm
         driver's side  59650  675,--  Passenger side 59594  285,20                     driver's side  59538  429,30
         Passenger side 596501  675,--                                                  Passenger side 59544  396,44
        For VW T6.1/T6/T5          For VW T4

                         With                         With                    435 mm  With                   With
                         TÜV                           TÜV                          TÜV                      TÜV


                                                                      430 mm
                                                                                                             370 mm

       Rotating base for VWT6/T5 driver
       +passenger side with ABE
       for driver side please order handbrake                                                  415 mm        17mm
       adapter 59616 too.
                 59653    249,--                             Rotating console original seat +
       Matching handbrake lowering  Swivel console for original seat  Sportscraft for My. 1996-2003  Adapter for Sportscraft seat to
       necessary with swivel bracket driver  My. 1996-2003   Centre rotating,with cable grommet  swivel base 59501.
       side                        Driver's side  59471  185,--  Driver's side/passenger's side.  Original rails required.
                 59616     35,95   Passenger side 594711  185,--        59501    259,--            59510    143,--

                                                                 The TÜV can also accept your vehicle without tested individual
      162   www.reimo.com                                        components, please clarify details with your test centre.
