FURNITURE MAKING ACCESSORIES

Roller shutter door
complete set
• For the construction of an upward opening roller shutter door
• For maximum door size of 100 cm height and 60 cm width
• Enables opening even in confined spaces
• Complete with cut-to-size roller shutter, rails and panel
The guide rails, roller shutter mat and retractable panel can be cut to the de-
sired door size and cabinet depth. Material: plastic.
Roller shutter door set
consisting of:
1 x Roller shutter mat with handle bar,
H 100 x W 60 cm,
4 x Guide rails for
to screw on, L 100 cm,
4 x Guide bends 90° to screw on
1 x retractable screen, L 100 cm.
Silver 53044 84,50
Structure, Beige 53045 89,90
NEW: Matte Black 53047 89,90

Texture, Matte
Silver Beige black

Mini pharmacy pullout with 2 shelves

• Perfect for narrow cabinets
• Drawers with ball bearings and
soft-close system
• Chrome-plated metal frame
with railing
• Furniture front individually at-
tachable and adjustable
Flaps lifting fitting HSB View of the ex-
• Hinge system for parallel lifting of flaps tract from the
• Space-saving opening in narrow aisles back
• Can also be used with wall cabinets
• Width can be shortened as required from 60 to 120 cm
• For flap heights up to max. 40 cm
The HSB swivel fitting can be used to open flaps in the foot The pull-out frame is supplied complete with the pull-out rails. It
area as well as flaps of wall cabinets smartly. For wall cabi- is mounted on the right side inner wall of the cabinet. The cabinet
nets, make sure that there is enough space above the cabi- body must have minimum internal dimensions of H 47 x W 12 x D
nets. The weight of the flap front must not exceed 7 kg. 28 cm. The cabinet front is mounted on the shelves and can be
53362 138,-- aligned with screws. 52320 142,--

Drawer pulls

• Narrow design, together only approx. 25 mm wide
• Loadable up to 30 kg 30 kg 46 mm
• Very good running properties, easy to unhinge
52 mm
With soft close

12,5 mm
12,5 mm Full-extension drawers
Load capacity 30 kg, Soft-Close-Automatic
300 mm, pair 53113 39,65
Partial extensions detachable 350 mm, pair 53102 39,95
300 mm, pair 53120 15,70 Full extension slides detachable 400 mm, pair 53105 45,95
350 mm, pair 53378 8,40 300 mm, pair 53370 32,30 450 mm, pair 53103 46,95
400 mm, pair 53376 8,90 400 mm, pair 53371 32,60 Mounting catch set (not shown)
550 mm, 53126 14,40 500 mm, pair 53372 36,-- for these slides 53114 9,--
