We recommend the following heating system:
Fig. shows decor Granitto Carbest VanHeat 2.0-DH
Diesel parking heater for mounting under the
Sleeping/seating bench Variotech® 3100 rigid Furniture line as a finished part without tech- passenger seat, power 2kW, incl. altitude kit up
Three-seater, total width: 1205 mm, cushion nology package including swivel table system to 5,000 m and control panel. With extensive
width: 1150 mm, sleeping surface: 1900x1310 Consisting of: Clothes/laundry cabinet with re- mounting material. Type approval according to
UN ECE R122, approval by the Federal Motor
mm. 3 integrated retractable headrests, 3 safety tractable door, additional laundry and storage Transport Authority according to UN ECE R10.
belts (size 10) .For maximum 2 child seats (mid- compartments in the rear area. In the gas box is
dle seat not usable when using a child seat). space for 2x 5 kg gas bottles. Kitchen section 48182 649,--
Fold-up rear cushion (storage height under rear with space for 2-burner stove and stainless steel
cushion: 46 cm), side panel. Ready upholstered sink. Plenty of space in storage compartments
incl. rear cushion Sleeping/seating bench not re- and drawer, space for refrigerator. Swivel table
movable. Table system included in the scope of system with attachment to the bench, compart-
delivery of the furniture line. Fabric design: Classic ment for Porta Potti Qube 335 (660102). Re-
gray, 2-color. cesses for laying gas, water and electric. Robust
5040600 3890,-- worktop in HPL laminate. Furniture line available
in decor apple laminate with edges in silver or
Mounting material bench seat decor Granitto. Swivel table system with bracket
Carrier 1 582081 32,95 for attachment to the front panel of the bench in-
Carrier 2 582082 44,95 cluded. Table top (approx. 80x 47 cm) decor
Carrier 4 582084 289,-- Pearl.
Mounting kit 58208 89,90 104900 as finished part, decor apple 2199,-- Compressor refrigerator CV50L High quality
Compressor refrigerator with 46 l volume incl.
104904 asfinished part, decor Granitto 1999,- freezer compartment. Door hinge on the right,
with LED operating display.
713572 679,--

Drawer, mounted
Provides additional storage space for e.g. shoes,
cables or on-board tools. The drawer can be re-
moved for loading long parts. Dimensions HxWxD:
17x49,5x69,5 cm. Décor: Basalt Hanging roof cabinet for EasyFit sleeping
roof with slatted bed
5040690 549,-- As a prefabricated laminate part above rear
bench seat for additional storage space. Cabinet
pre-assembled. For short or long wheelbase.
104941 as prefabricated part, apple decor379,--
104941GR as prefabricated part, decor granitto
381,92

Front panel, mounted
Mounted on the bench instead of a drawer. The
front panel is removable and therefore offers a
through-loading possibility for e.g. surfboard or Technology package, kit
skis up to a length of max. 2.4m. Through-load- (not installed in above furniture line)
ing dimensions centered under the bench The SportCamper technical package for self-in-
HxW approx. 31x60 cm. Decor: Basalt stallation includes: Water system with 2x 12 l
5040680 259,-- fresh water canister and 1x 16 l waste water can-
ister. Water tap, submersible pump 16 l and Portable camping toilet Porta Potti 335
Bottom plate 1-piece stainless steel sink. Gas system with 2-burner Suitable for SportCamper furniture line .High-
Made of waterproof chipboard with PVC covering. hob, gas regulator, hose, gas pipe and small quality plastic for maximum hygiene
For original VW door sill. Decor: ship's bottom. parts. 660102 169,50
1053812 358,11 10496T as kit 619,-
