REIMO TRAVELSTYLE - VW T6.1/T6/T5

Based on Volkswagen Transporter T6.1/T6/T5 station wagon, short wheelbase

Travel in style. Technical specifications
TravelStyle short wheelbase:

The 3-person bench seat with retractable headrests and 2 Isofix mounts for 2 child seats folds down into Sleeping berths on sleeper/seat bench 2
a comfortable double bed. Thanks to the removable front panel, long items such as surfboards and skis Light bed dimension sleeping bench 190 x 131 cm
can be easily loaded under the bench seat. Size of the through-loading facility: Sleeping places with optional sleeping roof 4
LxWxH approx. 240x60x28 cm. Roof bed dimension: 200 x 120 cm
Sleeping/seating bench: Variotech® 3000
The integrated 46 liter compressor refrigerator, the generous storage compartments and the prepared Seats with three-point seat belts 5
storage compartment for a mobile camping toilet (Porta Potti 335) leave nothing to be desired on a fam- Stove: 2-burner gas stove*
ily camping vacation Refrigerator: Compressor refrigerator, 46 l*
Gas capacity Space for 2x 5 kg gas bottle
Furniture construction Poplar plywood
with HPL laminate
Fresh water / waste water 2x 12 l / 16 l*
Tall cabinet 117 x 126 x 33 cm
Overhead cabinet: 97 x 36 x9 cm / approx. 32 l
Storage space
- in the sliding door area: 2000 l
- under bed extension: DxWxH 73x67x40 cm
- under the bench: 50x67x30 cm / 100 l
*Included in the technical package

Permissible total mass: 3000 kg
Payload without sleeping roof approx. 640 kg
Payload with sleeping roof approx. 580 kg

Day position

Night position

A clever detail of the equipment is the re-
tractable shelf, which can be easily swung
out of the kitchen block when needed and
provides additional work space.
1
The integrated water system with 2x 12
Litre canisters provides you with fresh
drinking water during your vacation.

For further equipment and options, please contact your specialist dealer
Equipment for the long wheelbase can be found at: www.reimo.com
Some of the illustrations show optional equipment that is not included in the scope of delivery.
Fig. 1 shows furniture line with additional cabinet
for long wheelbase.
