HIGH QUALITY BRAKE LIGHT CAMERAS

•High resolution cameras a
•Plug & Play Installation
•Night mode with night vision IR LEDs (except 47811 + 47813) ECE R10
•10 m connection cable included
•All brake light cameras are ECE R10 certified
•Compatible with the rear view mirrors on the left side
b
c

d
Compatible with the
Connection cable included w/ rear view mirrors
all brake light cameras on the left side

Video (Yellow)
Monitor/
Navigation Extension cable Camera connection cable
DC 12V
Model a Fiat Ducato / Peugeot b Volkswagen c Volkswagen d Volkswagen T6
Boxer / Citroën Jumper Caddy Crafter > 2017 > 2016 with large
etc. > 2006 tailgate
Camera system 1/3 CMOS 1/3 CMOS 1/3 CMOS 1/3 CMOS
Resolution (HxV) 720x480 Pixel 960x576 Pixel 960x576 Pixel 960x576 Pixel
TV system PAL PAL PAL PAL
Protection class IP68 IP69 IP69 IP69
Viewpoint 160° 170° 170° 170°
Horizontal resolution 600 TVL 700 TVL 700 TVL 700 TVL
IR LEDs 6 LEDs - 9 LEDs -
Power supply DC 12V DC 12V DC 12V DC 12V
Operating temperature -20°C - +70°C -30°C -s +70°C -30°C - +70°C -30°C - +70°C
Energy consumption < 3 W < 3 W < 3 W < 3 W
Built in lens 2,6 mm 2,8 mm 2,8 mm 2,8 mm
Connection cable, length 10 m 10 m 10 m 10 m
Housing dimensions app. 26 x 5,5 cm app. 17,5 x 4 cm app. 53 x 17,5 cm app. 33.5 x 2.5 cm
Item no. 47800 47811 47812 47813
Price 179,-- 44,49 152,15 109,65

RADIO REAR VIEW CAMERA SYSTEM

FOR MOTORHOMES AND CARAVANS

SHORT
CABLE-
12/24 V RADIO- LESS INSTAL-
SYSTEM ASSEMBLY LATION-
TIME ECE R10
The rear view camera system transmits the rear view camera image wirelessly via
radio to a monitor in the driver's cab (radio range max. 10 m). Radio range also
suitable for larger motorhomes and caravans. Wireless installation reduces the
installation time in the vehicle. Operation via 12 V or 24 V possible. Digital 2.4 GHz
radio transmission. Scope of delivery: 1 receiver, 1 transmitter, incl. adapter for
reversing systems. 47439 84,96

Cable tie Adhesive base for cable ties, 50 pcs.
Plastic base, back with 3M adhesive tape. For cable ties up to a
For quick attachment of hoses or cables. Plastic, assorted maximum width of 6 mm. Colour: black. Dimensions: 20 x 20 mm.
colours. Dimensions: 200 x 3.5 mm, 100 pcs. Cable ties not included in the scope of delivery.
810780 3,90
810800 4,99
