P. 248

FLEXIBLE SOLAR MODULES AND COMPLETE SETS









       Basic Panel Flex                                           WATT                170
                                                                   110
                                                                                      WATT
       MC-110 + MC-170 for economy foxes


         PET   TPT          90 cm   MC4
        TOP-  CARRIER  MONO  CABLE  SOLAR-
                                   PLUG +
        AREA   PLATE  CELLS  4.0 mm 2  SOCKET
       •Top price-performance ratio                             Basic Panel Flex MC-110  Basic Panel Flex MC-170
       •110 W or 170 W power             Power / Cell type      110 W / monocrystalline cells  170 W / monocrystalline cells
       •High power generation at low weight
       •Monocrystalline cells            Short circuit current (Isc)  6,67 A                 10,32 A
       •PET top layer                    Open circuit voltage (Voc)   21,12 V                21,12 V
       •TPT carrier plate                Rated voltage (Vmp)           18 V                   18 V
       •Incl. 90 cm connection cable     Rated current (Imp)          6,14 A                  9,48 A
       •With MC4 solar plug + socket     Operating temperature      -40°C  ~  +85°C        -40°C  ~  +85°C
                                         Dimensions in mm LxWxH     955x700x2,5            1370x700x2,5
                                         Cable (4.0mm ) pre-installed with  0,9 m             0,9 m
                                                 2
                                         MC4 male and female connector
                                         Weight                     approx. 2,5 kg         approx. 3,5 kg
                                         Carrier plate color           White                  White
                                         Art. No.                     853412                 853413
                                         Price                         219,--                 349,--
                                         Please order MC4 solar connector set (84052) for connection

       THE PRICE/PERFORMANCE WINNERS
       Black MC-100 + Black MC-140 Solar Complete Sets



         ALU   SAFE-         6 m      ALL SETS INCL          • All components are optimally matched to each other
        FRAME  HEITS  MONO  CABLE    BRACKET, CHARGE         • Aluminium holding profile (black) already pre-installed
                      CELLS
        BLACK  GLASS         2x 2,5 2  CONTROLLER, ROOF DUCT  • 6 m cable (2x 2.5 mm ) pre-installed
                                                                              2
                             mm
                                                             • Solar charge controller with USB port (5 V, 1.2 A)
                                                             • Complete black design
                                                             • Performance guarantee
                                                             • After 25 years still 80% power
                                                             Solar complete set 100 W and 140 W in black design
                                    140                      The sets include a solar module with pre-installed aluminium
                                    WATT                     mounting profile (spoiler), pre-installed 6m solar cable, roof feed-
                                                             through and solar charge controller 12 V/10 A. All components
                                                             are optimally matched to each other and thus ensure reliable op-
                                          With USB port      eration
                                           (5 V, 1.2 A)

        100                                                      Solar Set Black MC-100  Solar Set Black MC-140
        WATT                             Power / Cell type      100 W / monocrystalline cells  140 W / monocrystalline cells
                                         Efficiency                   19,60%                 20,70%
                                         Short circuit current (Isc)  6,00 A                  8,40 A
                                         Open circuit voltage (Voc)   21,6 V                  21,6 V
                                         Rated voltage (Vmp)           18 V                   18 V
                                         Rated current (Imp)          5,55 A                  7,77 A
                                         Operating temperature      -45°C  ~  +80°C        -45°C  ~  +80°C
                                         Dimensions solar panel   1353x508x35/64 mm      1370x688x35/64 mm
                                         incl. spoiler (L x W x H)
                                         Cable (2x 2,5mm ) pre-installed  6 m                 6 m
                                                   2
                                         Weight                     approx. 10 kg           approx. 12 kg
                                         Solar Charge Controller:  LS1012EU, 12V/10A, max. solar panel voltage 30V, 1x USB port 5V 1.2A
                                         Art. No.                     84033                  84034
                                         Price                        229,--                  299,--
