12/24 V MODULES FOR FREE COMBINATION                                                             12V
                                                                                                         24V








        Mounting frames                                        Surface-mounted housing
        Front panels to mount sockets or indicators. Individually configurable with all   Surface-mounted housing for mounting sockets or indicators. Individually
        CARBEST power sockets / USB sockets / voltmeters, hole diameter:    configurable with all CARBEST power sockets / USB sockets / voltmeters.
        Ø 29 mm. Dims. (L x W x H) mm                          Hole diameter: Ø 29 mm
        1-way   60 x 42,5 x 5,5 mm   811221        1,50        1-fold: dimensions (L x W x H): 80 x 55 x 50 mm   811223  2,60
        2-fold   105 x 42,5 x 5,5 mm      811222    1,90       2-fold: Dimensions (L x W x H): 80 x 100 x 50 mm   811224  4,50
        3-way   150 x 42,5 x 5,5 mm      811213    2,30        3-fold: Dimensions (L x W x H): 80 x 150 x 50 mm   811225  5,90
        4-way   195 x 42,5 x 5,5 mm      811226    2,90
        4-way (square) 100 x 110 x 8 mm    811227    3,20









        Rocker switch (ON/OFF)     Temperature display         LED voltmeter              Dual LED voltmeter for
        with control lighting      with probe                  3-digit digital display (illuminated   vehicle and on-board battery
        With red LED indicator light, rocker   3-digit digital display (illuminated red),   red), voltmeter (6 - 28V) for digital   3-digit digital display (illuminated in
        switch for switching on/off with red   Tempmeter incl. temperature sensor.   display of the voltage applied in   red), dual LED voltmeter (10 - 60V)
        indicator light. Load capacity: 12V   Reliable indication of the ambient   volts. Hole: Ø 29 mm  for displaying the voltage, ideal for
        - 10A / 24V - 6A. Hole: Ø 29 mm  temperature. Temperature range:       811218   14,60   monitoring the vehicle battery and
                                   -40 - 125°C, Hole: Ø 29 mm
               811217    2,90                                                             additional battery. Hole: Ø 29 mm
                                          811220   13,90                                         811219   19,90










        Power socket               Dual USB charging socket    LED voltmeter with integrated USB charging socket
        For operating 12V or 24V devices,   1x USB-A / 1x USB-C  LED voltage indicator (illuminated blue) incl. USB charging option, LED
        universal socket incl. protective cap.   USB built-in socket (illuminated blue)   voltmeter with integrated USB charging socket. The display can be switched on
        Also suitable as a charging input.   incl. protective cap. Input: 12V / 24V,   or off via an ON/OFF touch switch. Including protective rubber cap with cut-out
        Load capacity: 12V-20A/ 24V-10A.                       for reading the voltage, input: 12V / 24V, output USB-A: QC 3.0
        Hole: Ø 29 mm              Output USB-A: QC 3.0 (3.6V - 12V, max.   (3.6V - 12V, max. 18W), hole: Ø 29 mm
                                   32W), Output USB-C: QC 4.0 (5V - 20V,
               811210    4,20      max. 60W), Hole: Ø 29 mm                                 811212        18,50
                                          811211   19,90


        12/24 V POWER DISTRIBUTION


                                                     a
        Power distributor with fuse holder and LED
        failure indicator
        • LED failure indicator
        • Integrated negative rail
        • Transparent plastics cover
        • Includes pictogram sticker for labeling
        Compact fuse and distribution box for 6 or 12 circuits. A red LED
        light immediately signals when a fuse has blown. Load capacity per   Extra strong fuse module for FKS fuses
        circuit: max. 30A. Total load capacity: max. 100 A. Voltage:    b
        max. 32 V. (Supplied without fuses)
                                                                       Switch and distribution box SVB 13 12 V cut-off relay 30 A,
        a 6 Circuits, Dimensions: LxWxH 87.8 x 88 x 36.5 mm            battery monitor D+ simulator, 2 outputs, load fused with 20 A,
                       810220     24,95                                connection for charger. If the battery voltage of the 2nd battery
        b 12 Circuits, Dimensions: LxWxH: 165 x 85 x 39 mm,            is >13.7 V, the first battery is also charged.
                       810221     39,95                                Dims.: LxWxH 130x130x50 mm.   80090  117,02
