CURTAIN-TYPE ACRYLIC GLASS HINGED WINDOW
FOR PANEL VANS

OPTIONALLY
The curved acrylic glass OPTIONALLY
(Radius: 5800 mm) Blackout system
adapts perfectly to the vehicle with privacy and
contour Mosquito protection.
Pleated blind
with magnetic closure

Acrylic glassHinged window RW Rear RW Rear blackout system

LIGHT- MOSKITO- MATERIAL
ACRYLIC DOUBLE THROUGH- DISK TO OPTIONALLY DARKENING PROTEC- FRAME:
GLASS GLAZED TRANSMISSI- OUTSIDE AVAILABLE PLISSEE TION ALUMINI-
CURVED
ON: 10% PLISSEE UM
UV 3 LEVELS- E
RESIS- ADJUSTER FRAME-
LESS
TANT ECE R43
Installation Detail Outer dims. Max. Opening Weight Item no. Price Outer dims. Item no. Price
position W x H (mm) W x H (mm) (degree) (kg) W x H (mm)
Page 260x560 340x653 60° 1,6 31920 169,-- 347x669 319201 102,--
Page 735x560 814x653 60° 4,6 31922 243,-- 822x669 319221 119,--
Sliding door 970x560 1050x653 60° 5,8 31923 274,-- 1057x669 319231 129,--
Rear 620x560 700x653 60° 4,1 31921 199,-- 707x669 319211 117,--
Rear window does not fit with the 270° door hinges (Fiat Ducato). Not suitable for replacing the original glazing.

Order at the same time:
b
a Sealing rubber profile self-adhesive, for curtain wall windows
For wall thicknesses of 28-32 mm. Self-adhesive. Colour: Black b
4 m GP* 14,99 /1 m 322704 59,95 a
40 m GP* 13,97 /1 m 3227040 559,--
b Filler profile for rubber sealing profile 322704/3227040
Colour: grey, dims.: 23 mm x 0.9 mm.
10 m GP* 1,23/1 m 322730 12,30

a E
ECE R43
a Porthole - RW NAUTIC Ø 295 mm
• Tinted acrylic
• Double glazed
• UV-resistant Rigid
• Powder coated aluminum frame, black
• For wall thicknesses of 40 mm b
Rigid version (cannot be opened), outer Ø: 323 mm,
window Ø: 295 mm. Weight: approx. 1.4 kg.
32263 109,--
Sliding window for horse trailers - RW TRAILER
b Darkening system for RW NAUTIC
Window for horse trailers with protective grid, provides ventilation as well as
protection from insects due to integrated mosquito net. Lockable and lockab- •With privacy and Mosquito protection pleated
le from the outside. For 40 mm wall thickness, corner radius 100 mm. blind with magnetic closure.
Width 790 mm, height 515 mm 31970 296,65 Aluminum frame, white. Overall dims.: 374x318 mm,
weight: app. 1 kg
322631 59,90
