ACRYLIC WINDOW INCL. INSIDE FRAME



                                      +           GLASSED  BLACKOUT  PROTECTION     RESISTANT  ACRYL-  E 4

                                                                                      UV
                                                                                             GLASS
                                                   DOUBLE
                                                                   INSECTS-
                                                               Opening window CLASSIC

                                                               • Integrated blackout system (pleated)
                                                               • Integrated insect screen
                                                               • Manual telescopic shutters
                                                               • Double glazed
                                            Blackout system    • UV-resistant
                                                               • For wall thicknesses of 30 mm ± 1.5 mm
                                                               • Scope of delivery incl. inner frame
                                         Insect protection system  with blackout system, insect screen and screw cover
             Window and
             interior frame  Size       Cutout dimension Overall dimension  Opening angle Kg (approx.)  Item no.  Price
                 in set    500 x 300 mm  502 x 302 mm  529 x 329 mm  32°      3.8        318581       270,19
                           500 x 350 mm  502 x 352 mm  529 x 379 mm  60°      4.0        318580      279,73
                           500 x 450 mm  502 x 452 mm  529 x 479 mm  70°      4.2         31858      397,39
                           700 x 400 mm  702 x 402 mm  729 x 429 mm  70°      5,5         31859      359,23
                           900 x 450 mm  902 x 452 mm  929 x 479 mm  70°      7.0         31857      415,41
                           900 x 500 mm  902 x 552 mm  929 x 529 mm  70°      7.3        318582      399,51
                           1100 x 450 mm  1102 x 452 mm  1129 x 479 mm  70°   8.5         31855      459,93
                           1200 x 500 mm 1202 x 502 mm  1229 x 529 mm  78°    9.2         31868      493,85
                           1450 x 550 mm  1452 x 552 mm  1479 x 579 mm  70°   11.5        31869      527,77




                                                                                      UV    ACRYL-     E 4
                                          +                    • Window glass closes flush with the window frame on the outside
                                                                                             GLASS
                                                                                    RESISTANT
                                                   DOUBLE
                                                                   INSECTS-
                                                          BLACKOUT
                                                                   PROTECTION
                                                  GLASSED
 INTERIOR FRAME (OPTIONAL)                                     ELEGANCE vent window
            Acyl glass pane                                    • Pane cambered to the inside
                                                               • Thermally insulated acrylic pane
           closes flush with the
            frame on the out-                                  • For wall thicknesses from 25 to 40 mm
                side                                           • Scope of delivery incl. inner frame
                                                                 with blackout system, insect screen and screw cover
                                            Blackout system


                                         Insect protection system



                                      Size        Cutout dimension Overall dimension  Opening angle  Kg  Art. No.  Price
                                      500 x 350 mm  502 x 352 mm  529 x 379 mm  45°     4,3     318500   335,91
                      Window and      500 x 450 mm  502 x 452 mm  529 x 479 mm  45°     5,0     318501   353,93
                     interior frame   900 x 350 mm  902 x 352 mm  929 x 379 mm  45°     5,5     318507   368,77
                         in set
                                      900 x 450 mm  902 x 452 mm  929 x 479 mm  45°     7,4     318502   466,29
                                      1000 x 800 mm 1002 x 802 mm 1029 x 829 mm  50°    12,2    318506   713,27
                                      1100 x 450 mm 1102 x 452 mm 1129 x 479 mm  45°    10,4    318503   516,11
                                      1200 x 300 mm 1202 x 302 mm 1229 x 329 mm  12°    8,0     318504   480,07
                                      1200 x 500 mm 1202 x 502 mm 1229 x 529 mm  45°    10,0    318505   570,17
